JobShop¶

/********** jobshop.cpp **********/

#include <iostream>
#include <fstream>
#include <vector>
#include <limits>
#include <numeric>
#include <algorithm>
#include "localsolver.h"

using namespace localsolver;

class Jobshop {
private:
    // Number of jobs
    int nbJobs;
    // Number of machines
    int nbMachines;
    // Processing order of machines for each job
    std::vector<std::vector<int> > machineOrder;
    // Processing time on each machine for each job (given in the machine order)
    std::vector<std::vector<int> > processingTime;
    // Trivial upper bound for the start times of the activities
    int maxStart;

    // LocalSolver
    LocalSolver localsolver;
    // Decision variables: start times of the activities
    std::vector<std::vector<LSExpression> > start;
    // Decision variables: sequence of activities on each machine
    std::vector<LSExpression> jobsOrder;
    // Objective = minimize the makespan: end of the last activity of the last job
    LSExpression makespan;

    // The input files follow the "Taillard" format
    void readInstance(const std::string& fileName) {
        std::ifstream infile;
        infile.exceptions(std::ifstream::failbit | std::ifstream::badbit);
        infile.open(fileName.c_str());

        infile.ignore(std::numeric_limits<std::streamsize>::max(), '\n');
        infile >> nbJobs;
        infile >> nbMachines;
        infile.ignore(std::numeric_limits<std::streamsize>::max(), '\n');

        // Processing times for each job on each machine (given in the processing order)
        infile.ignore(std::numeric_limits<std::streamsize>::max(), '\n');
        std::vector<std::vector<int> > processingTimesInProcessingOrder
                = std::vector<std::vector<int> >(nbJobs, std::vector<int>(nbMachines));
        for (int j = 0; j < nbJobs; j++) {
            for (int m = 0; m < nbMachines; m++) {
                infile >> processingTimesInProcessingOrder[j][m];
            }
        }

        // Processing order of machines for each job
        infile.ignore(std::numeric_limits<std::streamsize>::max(), '\n');
        infile.ignore(std::numeric_limits<std::streamsize>::max(), '\n');
        machineOrder.resize(nbJobs);
        for (int j = 0; j < nbJobs; j++) {
            machineOrder[j].resize(nbMachines);
            for (int m = 0; m < nbMachines; m++) {
                int x;
                infile >> x;
                machineOrder[j][m] = x - 1;
            }
        }

        // Reorder processing times: processingTime[j][m] is the processing time of the
        // activity of job j that is processed on machine m
        for (int j = 0; j < nbJobs; j++) {
            processingTime.resize(nbJobs);
            for (int m = 0; m < nbMachines; m++) {
                processingTime[j].resize(nbMachines);
                std::vector<int>::iterator findM = std::find(machineOrder[j].begin(),
                        machineOrder[j].end(), m);
                unsigned int k = std::distance(machineOrder[j].begin(), findM);
                processingTime[j][m] = processingTimesInProcessingOrder[j][k];
            }
        }

        // Trivial upper bound for the start times of the activities
        maxStart = 0;
        for (int j = 0; j < nbJobs; j++)
            maxStart += std::accumulate(processingTime[j].begin(), processingTime[j].end(), 0);

        infile.close();
    }

public:
    Jobshop(const std::string& fileName) : localsolver() {
        readInstance(fileName);
    }

    void solve(int timeLimit) {
        // Declares the optimization model
        LSModel model = localsolver.getModel();

        // Integer decisions: start time of each activity
        start.resize(nbJobs);
        std::vector<std::vector<LSExpression> > end(nbJobs);
        for (unsigned int j = 0; j < nbJobs; j++) {
            start[j].resize(nbMachines);
            end[j].resize(nbMachines);
            for (unsigned int m = 0; m < nbMachines; m++) {
                start[j][m] = model.intVar(0, maxStart);
                end[j][m] = start[j][m] + processingTime[j][m];
            }
        }
        LSExpression startArray = model.array();
        LSExpression endArray = model.array();
        for (int j = 0; j < nbJobs; j++) {
            startArray.addOperand(model.array(start[j].begin(), start[j].end()));
            endArray.addOperand(model.array(end[j].begin(), end[j].end()));
        }

        // Precedence constraints between the activities of a job
        for (int j = 0; j < nbJobs; j++) {
            for (int k = 1; k < nbMachines; k++) {
                model.constraint(start[j][machineOrder[j][k]] >= end[j][machineOrder[j][k-1]]);
            }
        }

        // Sequence of activities on each machine
        jobsOrder.resize(nbMachines);
        for (int m = 0; m < nbMachines; m++) {
            jobsOrder[m] = model.listVar(nbJobs);
        }

        for (int m = 0; m < nbMachines; m++) {
            // Each job has an activity scheduled on each machine
            LSExpression sequence = jobsOrder[m];
            model.constraint(model.eq(model.count(sequence), nbJobs));

            // Disjunctive resource constraints between the activities on a machine
            LSExpression sequenceSelector = model.createLambdaFunction([&](LSExpression i) {
                return model.geq(model.at(startArray, sequence[i], m),
                        model.at(endArray, sequence[i-1], m));
            });
            model.constraint(model.and_(model.range(1, nbJobs), sequenceSelector));
        }

        // Minimize the makespan: end of the last activity of the last job
        makespan = model.max();
        for (int j = 0; j < nbJobs; j++) {
            makespan.addOperand(end[j][machineOrder[j][nbMachines-1]]);
        }
        model.minimize(makespan);

        model.close();

        // Parameterizes the solver
        localsolver.getParam().setTimeLimit(timeLimit);

        localsolver.solve();
    }

    // Writes the solution in a file with the following format:
    //  - for each machine, the job sequence
    void writeSolution(const std::string& fileName) {
        std::ofstream outfile(fileName.c_str());
        if (!outfile.is_open()) {
            std::cerr << "File " << fileName << " cannot be opened." << std::endl;
            exit(1);
        }
        std::cout << "Solution written in file " << fileName << std::endl;

        for (int m = 0; m < nbMachines; m++) {
            LSCollection finalJobsOrder = jobsOrder[m].getCollectionValue();
            for (int j = 0; j < nbJobs; j++) {
                outfile << finalJobsOrder.get(j) << " ";
            }
            outfile << std::endl;
        }
        outfile.close();
    }
};

int main(int argc, char** argv) {
    if (argc < 2) {
        std::cout << "Usage: jobshop instanceFile [outputFile] [timeLimit]" << std::endl;
        exit(1);
    }

    const char* instanceFile = argv[1];
    const char* outputFile = argc > 2 ? argv[2] : NULL;
    const char* strTimeLimit = argc > 3 ? argv[3] : "60";

    Jobshop model(instanceFile);
    try {
        const int timeLimit = atoi(strTimeLimit);
        model.solve(timeLimit);
        if (outputFile != NULL) model.writeSolution(outputFile);
        return 0;
    } catch (const std::exception& e) {
        std::cerr << "An error occurred: " << e.what() << std::endl;
        return 1;
    }
}
